SIZE mm (L*W*H)

13020*2510*3910

Working medium

LNG

Design pressure bar

6.5

Design temperature ℃

-196

Geometric volume m³

52.6

Effective volume m³

47.34

Safety Valve Set pressure bar

7.0

Running speed limit Km/h

Straight road

80(Arterial road)

30~40(Secondary and tertiary roads)

Turn

20

Curb Weight Kg

～18090

Rated load Kg

～20166

The degree of vacuum sealing Pa

≤1×10-1

Static evaporation rate %/d

≤0.21(liquid nitrogen ) OR ≤0.17(LNG)

Insulation form

High vacuum multi-layer insulation

Static leak rate Pa.m³/s

≤5×10-9 (Interlayer total leak and outgassing rate)

Inner Container(Material)

SA240 TP.304

Outer Tank(Material)

SA516 Gr.70

Standard

JB/T4783-2007 Cryogenic liquid tanker

TSG R0005-2011 Safety technical supervision rules for mobile pressure vessels                                 GB150.1-150.4-2011 Pressure vessel
